Stainless Steel Press 90° Long Elbow – S Type

Product Description

The LIANHE Stainless Steel Press 90° Long Elbow S Type is designed to change the direction of a compatible stainless steel pipeline by 90 degrees. Its extended bend profile provides a smoother directional transition than a compact elbow, helping maintain stable flow through water, gas and industrial piping systems.

Manufactured from mechanically formed stainless steel pipe, the elbow combines dimensional accuracy, corrosion resistance and reliable joint performance. The S-type press socket allows fast installation without conventional threading or on-site welding.

Technical Specifications

• Size Range: 1/4"–4" (DN10–DN100)

• Wall Thickness: 0.6–2.0 mm

• Applicable Standards: GB/T 19228.2-2011, CJ/T 152-2016, CJ/T 466-2014, EN, DIN and ASME

• Product Types: Type A and Type B

• Materials: SS304, SS304L, SS316 and SS316L

• Equivalent Grades: 0Cr18Ni9, S30408, SUS304, 1.4301, 0Cr17Ni12Mo2, S30403, 1.4306, S31603 and 1.4404

• Gasket Materials: CIIR, EPDM, PTFE and nitrile rubber

• Gasket Temperature Range: −20°C to 110°C

• Socket Connections: D type and S type

• Nominal Pressure: PN16

• Hydrostatic Test Pressure: 2.5 MPa

• Airtightness Test Pressure: 1.05 MPa

• Manufacturing Process: Mechanically formed from stainless steel pipe

• Surface Treatment: Vibration polishing, magnetic polishing or pickling

• Product Marking: Logo, outside diameter, wall thickness and material grade

• OEM Marking: Customer logos and customized markings available

• Applicable Media: Cold and hot drinking water, wastewater, industrial water, oil and gas

• HS Code: 7307230000

• Brand: LIANHE

• Place of Origin: Wenzhou, China

Actual pressure, temperature and media compatibility should be confirmed according to the selected stainless steel grade, gasket, pipe size and applicable system standard.

Product Advantages and Applications

Core Advantages

1. Structural strength: The mechanically formed elbow provides strength and dimensional stability for compatible piping installations.

2. Corrosion resistance: SS304, SS304L, SS316 and SS316L options are available for different operating environments.

3. Long service life: Stainless steel construction provides durability and can reduce replacement requirements.

4. Smooth flow transition: The long 90-degree bend supports a smoother change in flow direction.

5. Seismic performance: The mechanical press joint is suitable for appropriately designed systems exposed to vibration or movement.

6. Environmentally responsible material: Stainless steel is durable and recyclable.

7. Fast installation: The press connection reduces the need for conventional threading or on-site welding.

8. Concealed installation: The compact connection is suitable for exposed or embedded piping layouts, subject to applicable requirements.

9. Cost efficiency: Fast installation and limited maintenance can reduce overall piping-system costs.

10. Wear resistance: The stainless steel body provides durability under suitable operating conditions.

11. Hygienic applications: Compatible materials can be used in drinking-water systems that meet relevant sanitary requirements.

12. Reliable sealing: The correct pipe, gasket and press tool provide a secure and leak-resistant joint.

13. Accurate 90-degree routing: The elbow enables pipelines to change direction in restricted or planned pipe layouts.

Application Fields

The stainless steel press 90° long elbow can be used in engineering projects, ships, commercial buildings, residential buildings, hospitals, hotels, environmental protection facilities, heating installations and air-conditioning systems.

It is suitable for compatible water, gas, direct drinking-water, environmental protection, heating, air-conditioning and industrial water piping systems.

For steam, oil, gas or other demanding media, the stainless steel grade, gasket material, operating pressure and temperature should be confirmed before ordering.

Production Capacity and Equipment

LIANHE operates its own manufacturing facility in Wenzhou, China. The factory uses pipe forming, welding, machining, polishing and pressure-testing equipment to support the production of stainless steel press fittings.

Main production equipment includes:

• 5 automatic pipe-welding production lines

• 2 laser-cutting machines

• 2 laser-marking machines

• 5 vibration-polishing machines

• 2 magnetic-polishing machines

• 5 airtightness and hydraulic-testing units

• 3 forming machines

• 3 grooving machines

• 2 drilling machines

• 10 CNC lathes

• 6 end-facing machines

• 2 vertical water-expansion machines

• 2 frame-type water-expansion machines

• 10 pipe-bending machines

• 8 automatic argon-arc welding machines

• 4 hydraulic drawing machines

• 4 high-speed hydraulic punching machines

• Packaging and related production equipment

Quality Control System

Dedicated quality-control personnel perform in-process and final inspections. Products are inspected before shipment according to the applicable product specification and order requirements.

Eight-Step Quality Control Process

1. Inspect the raw-material grade, outside diameter and wall thickness.

2. Check the material length and pipe-end condition after cutting.

3. Inspect the socket, outside diameter and wall thickness after machining.

4. Check the elbow-forming area, weld dimensions and surface condition where applicable.

5. Inspect the surface, dimensions, bend shape and socket after heat treatment.

6. Check the finished surface after polishing or pickling.

7. Perform the applicable hydraulic and airtightness tests.

8. Verify product markings, quantities and packaging before shipment.

Testing and Delivery Inspection

Available test items may include:

• Hydrostatic testing

• Airtightness testing

• Pressure testing

• Negative-pressure testing

• Drawing tests

• Hot- and cold-water cycle testing

• Hydrostatic bending and torsion testing

• Hydrostatic vibration testing

• Hydrostatic impact testing

Delivery inspection covers the material, surface finish, dimensions, hydrostatic performance and airtightness according to the applicable inspection plan.

Certificates and Inspection Reports

The company’s listed certificates include:

• GB/T 19001-2016

• ISO 9001:2015

• CE

• Sanitary License

Subject to the product and order requirements, available inspection documents may include:

• EN 10204 3.1 material test certificate

• Raw-material inspection certificate

• Radiographic test report

• Hydraulic sealing test report

• Dimensional inspection report

• Third-party inspection report

Please confirm which certificates and reports apply to the selected elbow, production batch and destination market.

Packaging, Shipping and Trading Terms

• Packaging: Plastic bags, cartons and wooden cases

• MOQ: Generally 5–10 pieces

• Stock: Subject to the requested size, material and current inventory

• Samples: Free standard samples may be available; courier charges are not included

• Quotation Time: Normally within three hours after receiving complete requirements

• Price Validity: Generally 3–7 days, depending on material-market conditions

• Stock Delivery: Approximately 3–7 days for regular sizes available from stock

• Production Lead Time: Approximately 25 days

• Payment Terms: 30% T/T deposit and 70% balance before delivery; specific terms can be discussed

• Payment Methods: T/T, Western Union and PayPal

• Trade Terms: EXW, FOB, CFR, CIF, DDP and DDU

• Shipping Methods: By sea, air or international express

• Warranty: Standard one-year quality warranty

If a confirmed product-quality issue occurs within the applicable warranty conditions, LIANHE will work with the customer to provide an appropriate solution.
