Brand: LIANHE
Size Range: 1/4"–4" (DN10–DN100)
Wall Thickness: 0.6–2.0 mm
Available Materials:
SS304, 0Cr18Ni9, S30408, SUS304, and 1.4301
SS304L, S30403, and 1.4306
SS316 and 0Cr17Ni12Mo2
SS316L, S31603, and 1.4404
Applicable Standards: GB/T 19228.2-2011, CJ/T 152-2016, CJ/T 466-2014, EN, DIN, and ASME
Connection Profiles: D-Type and S-Type
Sealing-Ring Materials: CIIR, EPDM, PTFE, and NBR
Nominal Pressure: PN16
Hydrostatic Test Pressure: 2.5 MPa
Airtightness Test Pressure: 1.05 MPa
Gasket Temperature Range: -20°C to +110°C, depending on gasket material and transported medium
Manufacturing Process: Mechanically formed from stainless steel pipes
Surface Treatment: Vibration Polishing, Magnetic Polishing, or Pickling
Product Marking: LOGO + Outside Diameter + Wall Thickness + Material. Customized logos and markings are available.
Packaging: Plastic Bags, Export Cartons, and Wooden Cases
Certificates: GB/T 19001-2016, ISO 9001:2015, CE documentation for applicable products, and Sanitary License
HS Code: 7307230000
Place of Origin: Wenzhou, Zhejiang, China
LIANHE manufactures stainless steel pipeline components for water, gas, heating, air-conditioning, and compatible industrial fluid systems.
Available in SS304, SS304L, SS316, and SS316L, the products provide good corrosion resistance, mechanical strength, and long-term performance under suitable operating conditions.
D-type and S-type connection profiles are available to meet different piping-system and installation-tool requirements. Multiple sealing-ring materials can be selected according to the transported medium, working pressure, and temperature.
Stainless steel construction with good corrosion resistance
D-type and S-type connection options
SS304, SS304L, SS316, and SS316L materials
CIIR, EPDM, PTFE, and NBR sealing-ring options
PN16 nominal pressure
Mechanically formed construction
Multiple surface-treatment options
Customized logos and product markings
Export packaging for international delivery
The connection profile, sealing ring, material, pressure, temperature, and medium compatibility must be confirmed before ordering. D-type and S-type products may require different pressing tools and jaws.
Suitable for compatible applications in:
Drinking-water systems
Cold- and hot-water pipelines
Wastewater systems
Industrial water pipelines
Heating and air-conditioning systems
Commercial and residential buildings
Hospitals and hotels
Ships and marine installations
Environmental protection equipment
Oil and gas systems, subject to technical confirmation
Steam, gas, oil, and drinking-water applications require appropriate material, gasket, testing, and regulatory confirmation.
Available tests include:
Hydrostatic Pressure Test
Airtightness Test
Negative-Pressure Test
Pull-Out Test
Cold- and Hot-Water Temperature-Cycling Test
Hydrostatic Bending and Torsion Test
Hydrostatic Vibration Test
Hydrostatic Impact Test
The applicable test items and sampling ratios depend on the product specification, standard, and order requirements.
LIANHE applies in-process and final inspection throughout production:
Inspect raw-material grade, outside diameter, and wall thickness.
Check length and pipe-end condition after cutting.
Inspect socket dimensions and wall thickness after forming.
Check weld dimensions and surface quality where applicable.
Inspect product dimensions after heat treatment.
Verify surface quality after polishing or pickling.
Perform hydraulic-pressure and airtightness tests.
Check product markings, quantities, and packaging before shipment.
Available documents include:
EN 10204 3.1 Material Test Certificate
Raw-Material Inspection Certificate
Dimensional Inspection Report
Hydraulic and Airtightness Test Report
Radiographic Testing Report, when applicable
Third-Party Inspection Report
Our factory is equipped with automatic pipe-welding lines, laser-cutting machines, forming machines, CNC lathes, pipe-bending equipment, polishing machines, grooving equipment, hydraulic and airtightness testing units, laser-marking machines, and export-packaging equipment.
MOQ: Normally 5–10 pieces, depending on product specification and stock availability.
Free Samples: Available for selected standard products; express delivery costs are normally paid by the recipient.
Quotation Time: Normally within three working hours after receiving complete specifications.
Delivery Time: Approximately 3–7 days for regular products available from stock and approximately 25 days for new production.
Payment Terms: 30% T/T deposit and 70% balance before delivery. Western Union, PayPal, and other agreed methods are available.
Shipping Terms: EXW, FOB, CFR, CIF, DDP, and DDU.
Transportation: Sea, air, land transportation, or international express.
Warranty: One year against confirmed manufacturing defects.
Manufacturer: LIANHE
Place of Origin: Wenzhou, Zhejiang, China
