Stainless Steel Ring Crimping Tee
  • Stainless Steel Ring Crimping TeeStainless Steel Ring Crimping Tee
  • Stainless Steel Ring Crimping TeeStainless Steel Ring Crimping Tee

Stainless Steel Ring Crimping Tee

Brand: LIANHE;
Size Range: 1/2”~4" (DN15~DN100);
Thickness:0.8~2MM;
Material: SS304, SS304L, SS316 or SS316L; confirm the required grade and designation for the order.;
Standards: Confirm the applicable standard for the specified product

    Stainless Steel Ring Crimping Tee Specifications

    Product Specifications

    Specification Details
    Size Range 1/2"–4" (DN15–DN100)
    Wall Thickness 0.8–2.0 mm
    Applicable Standards GB, EN, DIN and ASME
    Connection Type Ring crimping socket end
    Nominal Pressure PN16
    Hydrostatic Test Pressure 2.5 MPa
    Airtightness Test Pressure 1.05 MPa
    Manufacturing Process Mechanically formed from stainless steel pipe
    Surface Treatment Vibration polishing, magnetic polishing or pickling
    Gasket Temperature Range −20°C to 110°C
    Brand LIANHE
    HS Code 7307230000
    Place of Origin Wenzhou, China

    Actual operating pressure and temperature should be confirmed according to the selected material, gasket, conveyed medium, pipe size and applicable project standard.

    Stainless Steel Material Options

    Confirm the required stainless steel grade and material designation for each ring crimping tee order:

    Stainless Steel Grade Equivalent Designations
    SS304 0Cr18Ni9 / S30408 / SUS304 / 1.4301
    SS304L S30403 / 1.4306
    SS316 0Cr17Ni12Mo2 / SUS316
    SS316L S31603 / 1.4404

    SS304 is commonly selected for general water-supply and building-service applications. SS316 and SS316L may be considered for applications requiring additional corrosion resistance.

    The final material should be selected according to the operating medium, temperature, pressure, installation environment and applicable technical standard.

    Ring Crimping Connection

    The socket end uses a ring crimping connection. During installation, the pipe is inserted into the socket and compressed with the appropriate ring crimping tool.

    Each tee socket connects a compatible tube using the specified gasket and ring crimping tool, without conventional threading or on-site welding.

    Product Marking and OEM Service

    Standard product marking can include:

    • LIANHE logo

    • Outside diameter

    • Wall thickness

    • Material grade

    Customer logos and customized markings can be provided according to confirmed order requirements.

    Surface Treatment

    Available surface-treatment options include:

    • Vibration polishing

    • Magnetic polishing

    • Pickling

    The appropriate finish can be selected according to the product specification, application and customer requirements.

    Packaging

    Standard export packaging consists of:

    • Plastic bags

    • Cartons

    • Wooden cases

    Customized labels, cartons and packing arrangements can be discussed according to the order quantity and shipping method.

    Quality Management and Certificates

    The company’s listed management and certification documents include:

    • GB/T 19001-2016

    • ISO 9001:2015

    • CE

    • Sanitary License

    The applicability of individual certificates may vary according to the product, material and intended market. Please contact Lianhe to confirm the documents available for your selected ring crimping tee.

    Applicable Media

    Depending on the selected stainless steel grade, gasket material and operating conditions, the product may be used with:

    • Cold drinking water

    • Hot drinking water

    • Wastewater

    • Industrial water

    • Oil

    • Gas

    • Other compatible fluids

    Compatibility should be confirmed before the product is used with chemicals, oil, gas, steam or other demanding media.

    Typical Applications

    Stainless steel ring crimping tees connect three compatible pipe runs in:

    • Engineering projects

    • Ships and marine installations

    • Commercial buildings

    • Residential buildings

    • Hospitals

    • Hotels

    • Environmental protection projects

    • Heating systems

    • Air-conditioning systems

    • Industrial facilities

    Applicable Piping Systems

    The product may be incorporated into compatible:

    • Water piping systems

    • Gas piping systems

    • Direct drinking-water systems

    • Environmental protection piping systems

    • Heating piping systems

    • Air-conditioning piping systems

    • Industrial water piping systems

    • Other stainless steel ring crimping systems

    For steam systems, confirm the gasket material, pressure rating and operating-temperature requirements with Lianhe before ordering.

    Product Advantages

    High Structural Strength

    The mechanically formed stainless steel construction provides strength and dimensional stability for compatible piping applications.

    Corrosion Resistance

    SS304, SS304L, SS316 and SS316L material options are available for different operating environments and corrosion-resistance requirements.

    Long Service Life

    Stainless steel provides durability and wear resistance, helping reduce replacement and maintenance requirements when the product is correctly selected and installed.

    Low Flow Interference

    The tee provides a branch connection between compatible tube runs; confirm the flow and sizing requirements for the system.

    Seismic and Vibration Performance

    The mechanical ring crimping connection can provide reliable joint performance in appropriately designed piping installations subject to vibration or movement.

    Environmentally Responsible Material

    Stainless steel is durable and recyclable, making it suitable for long-life piping installations.

    Fast Installation

    The ring crimping connection reduces the need for conventional threading or on-site welding, helping simplify installation.

    Suitable for Concealed Installation

    The compact connection is suitable for both exposed and concealed piping systems, subject to applicable construction and inspection requirements.

    Cost-Effective System Installation

    Fast installation, durable stainless steel construction and limited routine maintenance can help reduce the overall cost of the piping system.

    Wear Resistance

    The stainless steel body provides resistance to wear under suitable operating conditions.

    Suitable for Hygienic Water Applications

    The product can be used in compatible drinking-water systems when the selected material, gasket and complete piping system meet the relevant sanitary requirements.

    Reliable Sealing

    When installed with the correct gasket, tube and crimping tool, the tee connects three compatible tube runs.

    Available Test Items

    Testing may include:

    • Hydrostatic testing

    • Airtightness testing

    • Pressure testing

    • Negative-pressure testing

    • Drawing tests

    • Hot- and cold-water cycle testing

    • Hydrostatic bending and torsion testing

    • Hydrostatic vibration testing

    • Hydrostatic impact testing

    The specific test program should be confirmed according to the product specification, applicable standard and order requirements.

    Delivery Inspection

    Delivery inspection may cover:

    • Material grade

    • Surface condition

    • Product dimensions

    • Hydrostatic performance

    • Airtightness

    Available Inspection Reports

    Subject to the product and order requirements, the following documents may be available:

    • EN 10204 3.1 material test certificate

    • Raw-material inspection certificate

    • Radiographic test report

    • Hydraulic sealing test report

    • Dimensional inspection report

    • Third-party inspection report

    Please confirm the required reports before ordering. Some reports may apply only to specific products, production batches or inspection arrangements.

    Product Quality Control

    Lianhe applies in-process and final inspection procedures throughout production. Products are inspected before shipment according to the applicable specification and order requirements.

    1. Raw-Material Inspection

    The stainless steel grade, outside diameter and wall thickness are checked before production.

    2. Cutting Inspection

    After cutting, the material length and pipe-end condition are inspected.

    3. Forming and Machining Inspection

    After mechanical processing, the socket dimensions, outside diameter and wall thickness are checked.

    4. Forming and Weld Inspection

    Where applicable, the formed area, weld dimensions and surface condition are inspected.

    5. Post-Treatment Inspection

    After heat treatment, the product surface, dimensions and socket geometry are checked.

    6. Surface-Finish Inspection

    After polishing or pickling, the finished surface is inspected against the applicable quality requirements.

    7. Hydraulic and Airtightness Inspection

    Products undergo the applicable hydraulic and airtightness inspection according to the product specification and inspection plan.

    8. Marking and Packaging Inspection

    Product markings, quantities and packaging are checked before shipment.

    Production Equipment

    Production and inspection equipment for stainless steel press and ring crimping products includes:

    • 5 automatic pipe-welding production lines

    • 2 laser-cutting machines

    • 5 vibration-polishing machines

    • 2 magnetic-polishing machines

    • 5 airtightness and hydraulic-testing units

    • 3 forming machines

    • 3 grooving machines

    • 2 drilling machines

    • 10 CNC lathes

    • 6 end-facing machines

    • 2 vertical water-expansion machines

    • 2 frame-type water-expansion machines

    • 10 pipe-bending machines

    • 8 automatic argon-arc welding machines

    • 4 hydraulic drawing machines

    • 4 high-speed hydraulic punching machines

    • 2 laser-marking machines

    • Packaging and related production equipment

    Payment Terms

    The standard payment arrangement is:

    • 30% T/T deposit

    • 70% T/T balance before delivery

    Specific payment terms can be discussed according to the order. Available payment methods may include:

    • T/T

    • Western Union

    • PayPal

    Trade and Shipping Terms

    Available trade terms include:

    • EXW

    • FOB

    • CFR

    • CIF

    • DDP

    • DDU

    Orders can be shipped:

    • By sea

    • By air

    • By international express

    MOQ and Stock Availability

    The general minimum order quantity is 5–10 pieces.

    Stock availability depends on the requested product, size, material and current inventory. Please contact Lianhe to confirm available quantities and the earliest delivery date.

    Samples

    Free samples may be available for quality evaluation. Courier or express delivery charges are not included and are normally borne by the customer.

    Sample availability should be confirmed according to the requested size, material and specification.

    Quotation and Delivery

    Item Details
    Quotation Time Normally within 3 hours after receiving complete requirements
    Price Validity Generally 3–7 days, depending on material-market conditions
    Delivery for Regular Sizes Approximately 3–7 days when available from stock
    Production Lead Time Approximately 25 days

    Actual quotation and delivery times depend on the product specification, quantity, stock availability, production schedule and shipping requirements.

    After-Sales Service

    The standard quality warranty period is one year.

    If a confirmed product-quality issue occurs within the applicable warranty conditions, Lianhe will work with the customer to determine an appropriate solution.

    Our Services

    Market-Specific Support

    Our sales team works with customers from different markets and can assist with market-specific product, marking, packaging and documentation requirements.

    Manufacturer in Wenzhou, China

    Lianhe operates its own manufacturing facility in Wenzhou, China, supporting the production and supply of stainless steel fittings and related products.

    Technical Support

    Our technical team can assist with material selection, product specifications, connection requirements and customized production.

    Cost and Production Management

    Production planning and cost management help us provide commercially competitive quotations based on the required material, quantity and specification.

    Experience in Press-Fitting Production

    Our team has experience in the production, inspection, sales and order management of stainless steel press and ring crimping fittings.

    Information Required for a Quotation

    For an accurate quotation, please provide:

    • Product name

    • Required size

    • Wall thickness

    • Stainless steel grade

    • Applicable standard

    • Required quantity

    • Conveyed medium

    • Working pressure

    • Operating temperature

    • Gasket requirement

    • Product-marking or OEM requirements

    • Packaging requirements

    • Required inspection documents

    • Destination country

    • Preferred trade terms

    Contact Lianhe for technical confirmation, current stock, sample availability and pricing.
