Stainless Steel Sanitary 45° Elbow

Product Description

The LIANHE Stainless Steel Sanitary 45° Elbow is designed to change the direction of flow by 45 degrees in sanitary and hygienic piping systems. Its smooth curved structure helps maintain efficient fluid movement while reducing unnecessary turbulence and pressure loss.

Manufactured from corrosion-resistant stainless steel, the sanitary elbow is suitable for food, beverage, dairy, drinking-water, pharmaceutical, biotechnology, and other compatible hygienic processing applications.

Long-type and short-type configurations are available to accommodate different pipeline layouts and installation-space requirements. Multiple sizes, wall thicknesses, stainless steel grades, dimensional standards, surface finishes, and customized markings can be supplied according to customer specifications.

Technical Specifications

Product Name: Stainless Steel Sanitary 45° Elbow

Size Range: DN15–DN300

Elbow Angle: 45 Degrees

Available Wall Thicknesses: 1.5 mm, 1.65 mm, 2.0 mm, 3.0 mm, and 4.0 mm

Wall thickness varies according to the selected size, dimensional standard, connection dimensions, operating conditions, and project requirements.

Available Materials:

• SS304 and S30408

• SS304L and S30403

• SS316 and SUS316

• SS316L and S31603

Applicable Standards: 3-A, SMS, IDF, DIN 11850/11851, ISO 2037, BS 4825, and JIS G 3447

Available Configurations: Long Type and Short Type

Product Marking: LOGO–Size–Material. Products can also be marked according to customer requirements.

Surface Treatment: Internal and External Polishing, up to 320 Grit

Standard Packaging: Plastic Packaging, Export Cartons, Woven-Bag Protection, and Wooden Cases

Certificates: GB/T 19001-2016, ISO 9001:2015, and CE documentation for applicable products

Brand: LIANHE

HS Code: 7307290000

Place of Origin: Wenzhou, Zhejiang, China

The final size, wall thickness, material grade, end dimensions, surface finish, and applicable standard should be confirmed according to the intended application and mating pipeline components.

Product Applications

The stainless steel sanitary 45-degree elbow can be used in hygienic processing and fluid-transfer systems, including:

• Drinking-water systems

• Dairy-processing pipelines

• Milk-production equipment

• Beer and brewing systems

• Beverage-processing lines

• Liquid-food production equipment

• Pharmaceutical-processing systems

• Biotechnology facilities

• Cosmetic-production equipment

• Clean-in-place piping systems

• Sanitary tanks and vessels

• General hygienic fluid-transfer applications

The 45-degree bend provides a gradual change in pipeline direction and can be used where a 90-degree turn is unnecessary or where the piping layout requires a smoother directional transition.

Before ordering, customers should confirm the compatibility of the stainless steel grade with the transported medium, operating temperature, system pressure, cleaning chemicals, and sanitation procedures.

Product Advantages

1. Smooth 45-degree change in flow direction

2. Excellent corrosion and oxidation resistance

3. Long operating service life

4. Smooth internal surface with low flow resistance

5. Reduced turbulence compared with sharper directional changes

6. Durable and recyclable stainless steel construction

7. Convenient installation and maintenance

8. Long-type and short-type configurations available

9. Multiple stainless steel grades available

10. Suitable for compatible hygienic processing systems

11. Internal and external polished surfaces

12. Customized markings and packaging supported

The smooth internal surface helps reduce the accumulation of process residues and makes routine cleaning more convenient. This supports applications where hygiene, cleanliness, and product purity are important.

Actual sanitary performance depends on the complete piping system, including product geometry, surface roughness, weld quality, sealing components, drainage conditions, installation procedures, and cleaning processes.

Long-Type and Short-Type Options

Long Type

The long-type configuration provides a larger bend radius and a more gradual directional transition. It may help reduce turbulence and pressure loss in applications where sufficient installation space is available.

Short Type

The short-type configuration is suitable for piping layouts with restricted installation space. Its compact dimensions can simplify routing around equipment and other pipeline components.

The exact centerline radius and dimensional difference between the long and short versions should be confirmed according to the selected standard and product drawing.

Dimensional Standards

Available dimensional standards include 3-A, SMS, IDF, DIN 11850/11851, ISO 2037, BS 4825, and JIS G 3447.

These standards may specify different outside diameters, wall thicknesses, bend radii, centerline dimensions, end dimensions, tolerances, and surface requirements.

Products manufactured according to different standards may not be directly interchangeable, even when their nominal sizes appear similar.

Customers should provide the exact required standard, size, wall thickness, bend radius, end dimensions, and mating-pipe information when requesting a quotation.

For replacement or maintenance projects, technical drawings or physical samples are recommended to verify compatibility with the existing sanitary piping system.

Surface Treatment

The internal and external surfaces can be polished using a process specified as up to 320 grit.

A polished surface helps improve product cleanliness, appearance, corrosion resistance, and resistance to the accumulation of process residues.

If a project requires a specific surface roughness, the required Ra value and measurement location should be stated separately. A polishing-grit designation alone does not guarantee a fixed Ra value.

Additional polishing, passivation, cleaning, or surface-finish inspection can be arranged according to project requirements.

Product Marking

Standard product markings may include:

• LIANHE logo

• Product size

• Stainless steel material grade

• Batch or traceability information, when required

Customer logos, private brands, project numbers, heat numbers, and other customized markings can be applied according to confirmed order requirements.

Delivery Inspection

Products are inspected before shipment. Standard delivery inspection covers:

• Stainless steel material grade

• Outside diameter and wall thickness

• Elbow angle

• Bend radius and centerline dimensions

• End dimensions

• Internal and external surface condition

• Weld appearance, where applicable

• Hydrostatic testing, where required

• Product markings

• Quantities and packaging

Additional inspection items can be arranged according to the applicable standard, intended application, and customer requirements.

Factory Inspection Reports and Certificates

Inspection reports and supporting quality documents can be supplied according to the confirmed specifications and order requirements, including:

• EN 10204 3.1 Material Test Certificate

• Raw-Material Inspection Certificate

• Radiographic Testing Report, when applicable

• Hydraulic Test Report, where applicable

• Dimensional Inspection Report

• Surface-Finish Inspection Report

• Third-Party Inspection Report

• Other project-specific quality documents

The required inspection scope, testing ratio, documentation, surface-finish requirements, and third-party witnessing arrangements should be confirmed before production.

Product Quality Control

LIANHE applies in-process and final inspection procedures throughout raw-material preparation, cutting, forming, machining, welding, surface finishing, testing, marking, and packaging.

The principal quality-control procedures include:

1. Inspecting the outside diameter, wall thickness, material grade, documentation, and surface condition of incoming raw materials.

2. Checking the length, cutting position, and end condition of raw materials after cutting.

3. Inspecting the outside diameter, wall thickness, elbow angle, bend radius, end dimensions, and other critical measurements after machining and forming.

4. Checking weld dimensions, weld appearance, alignment, and surface quality after welding, where applicable.

5. Inspecting the internal and external surfaces after polishing and other surface-treatment procedures.

6. Performing hydrostatic or airtightness testing according to the applicable product and inspection requirements.

7. Inspecting product markings, quantities, packaging materials, labels, and shipping marks before shipment.

Products are approved for delivery after completing the applicable inspection procedures.

Packaging

Each sanitary 45-degree elbow is protected with plastic packaging to reduce exposure to dust, moisture, scratches, and surface contamination.

Products are then packed in export cartons, wrapped with woven-bag protection where required, and consolidated in wooden cases for international transportation.

Customized cartons, customer logos, labels, barcodes, pallet packing, and other export packaging arrangements can be provided according to confirmed requirements.

Minimum Order Quantity and Stock

Minimum Order Quantity: Normally 5–10 pieces, depending on the product size, material, dimensional standard, and current inventory.

We maintain inventory for many regular products and commonly requested sizes. Selected products may have up to 5,000 pieces available.

Because inventory levels change continuously, actual stock quantities and immediate-delivery availability should be reconfirmed when requesting a quotation.

Samples and Quotation

Free Samples: Samples may be provided free of charge for dimensional verification and quality evaluation. International express delivery charges are normally paid by the recipient.

Quotation Time: Normally within three working hours after receiving the complete size, material, dimensional standard, wall thickness, quantity, and delivery information.

Quotation Validity: Normally 3–7 days, subject to stainless steel raw-material prices, exchange rates, and current market conditions.

Delivery Time

Regular-size products available from stock can normally be delivered within 3–7 days.

Orders requiring new production normally take approximately 25 days. The actual delivery schedule depends on the selected size, material, dimensional standard, order quantity, inspection requirements, packaging, and current factory production plan.

After-Sales Service

Our standard product quality warranty period is one year.

If a manufacturing-related quality problem is confirmed during the warranty period, our team will investigate the cause and provide an appropriate technical or after-sales solution.

Customers should provide the order number, product size, material grade, dimensional standard, wall thickness, installation conditions, transported medium, and relevant photos or videos to assist with technical evaluation.

Manufacturer: LIANHE
Place of Origin: Wenzhou, Zhejiang, China
