Stainless Steel Vertical Check Valve Full Bore 1/4" To 4"

Stainless Steel Vertical Check Valve is designed to allow flow in one direction and limit reverse flow in a compatible line. Confirm the required vertical installation orientation, thread form and size, body and seal materials, and operating conditions for the selected configuration.

    Description of Stainless Steel Threaded Check Valve

    The LIANHE Stainless Steel Threaded Check Valve is designed to provide reliable backflow prevention and stable fluid control in industrial and commercial piping systems. The valve automatically opens when the upstream pressure reaches the required level and closes when the flow stops or reverses, helping protect pumps, pipelines, and other system equipment from reverse-flow damage.

    Manufactured using precision investment casting and CNC machining, the valve provides good structural strength, accurate dimensions, dependable sealing, and consistent operating performance. Its compact threaded design allows it to be installed easily in restricted pipeline spaces while simplifying maintenance and replacement.

    The full-bore flow passage helps reduce pressure loss and flow resistance, improving the operating efficiency of the piping system. Stainless steel construction also provides excellent resistance to corrosion, moisture, and a wide range of compatible fluids, making the valve suitable for demanding working environments.

    Technical Specifications

    Our stainless steel threaded check valves are available in different sizes, thread standards, materials, and structural configurations to meet various pipeline and engineering requirements.

    Parameter

    Specification

    Size Range

    1/4"–4" (DN8–DN100), Full Bore

    Valve Types

    Vertical Check Valve, Horizontal Check Valve, Wafer Check Valve

    End Connections

    Female Threaded Connection, available with BSPT, BSP, NPT, DIN 259/2999, and ISO 228 threads

    Manufacturing Process

    Investment-Cast Valve Body with Precision CNC Machining

    Working Pressure

    Up to 200 PSI

    Operating Principle

    Automatic operation activated by fluid flow and pressure difference

    Material Grades

    CF8, CF8M, SS304, SS316 stainless steel

    Structural Options

    Swing-Type Disc, Integral Seat, and other model-specific sealing structures

    Applicable Media

    Water, oil, gas, and other fluids compatible with stainless steel and the selected sealing material

    Brand

    LIANHE

    Country of Origin

    Wenzhou, China

    The exact operating pressure, temperature range, thread standard, sealing material, and installation direction should be confirmed according to the selected valve model and actual pipeline conditions.

    Typical Applications

    This stainless steel check valve can be used in a wide variety of fluid-control and pipeline applications, including:

    • Building water supply and drainage systems

    • Industrial water-treatment equipment

    • Refrigeration and cooling systems

    • Fuel-gas and compatible gas pipelines

    • Food and beverage processing equipment

    • Medical and sanitary facility pipelines

    • Environmental protection equipment

    • Chemical-processing systems

    • Pump outlets and pressure-control systems

    • Oil, water, and general industrial fluid pipelines

    Before installation, customers should confirm the compatibility of the valve-body material, sealing components, pressure rating, temperature range, and process medium.

    Packaging, Shipping and Payment

    Standard Export Packaging

    Each valve is protected with a plastic bag to reduce exposure to moisture and dust. The products are then packed in reinforced cartons and consolidated in wooden cases or on export pallets when required.

    This multilayer packaging method helps prevent impact, contamination, and surface damage during handling and international transportation. Customized packaging, private labels, barcodes, and customer logos can also be provided according to order requirements.

    Payment Terms

    The standard payment term is a 30% T/T deposit, with the remaining 70% balance paid before shipment. L/C at sight may also be accepted for qualified orders. Western Union, PayPal, and other payment arrangements can be discussed according to the order value and cooperation conditions.

    Shipping Terms

    Available international trade terms include EXW, FOB, CFR, and CIF. Transportation can be arranged by sea, air, land, or international express service according to the order quantity, destination, delivery schedule, and customer preference.

    Free Samples

    Free samples may be provided for product testing, dimensional verification, and quality evaluation. The sample itself can be supplied free of charge, while the express delivery cost is normally paid by the recipient.
