Stainless Steel Class 150 Slip-On Flange with a plain bore and bolt holes. Confirm the mating pipe outside diameter, flange standard, facing, bolt pattern and stainless steel grade for the selected Class 150 configuration.
The main photograph shows a flange with a plain center bore and bolt holes. In the slip-on configuration, a compatible pipe passes through the bore and is secured by welding. The flange then forms a bolted joint with a matching flange and gasket.
Technical Specifications
Flange type: Slip-on flange for a compatible pipe outside diameter.
Pressure designation: Class 150 for the product named on this page; confirm the exact standard, dimensions and pressure–temperature limits for the ordered size and material.
Facing and bolt pattern: Specify the required facing and flange standard to match the mating connection.
Material: Specify the stainless steel grade and any required material certificate.
Ordering Information
Please provide the flange standard, nominal size, mating pipe outside diameter, facing, material grade, quantity and any drawing or inspection requirements.
