Stainless Steel S-Type Press Union Coupling

Product Description

The LIANHE Stainless Steel S-Type Press Union Coupling connects two compatible pipes of the same nominal diameter.

Its flame-free press connection simplifies installation and reduces the need for on-site welding or threading. Stainless steel construction provides good corrosion resistance, mechanical strength, and long service life.

Technical Specifications

Size Range: 1/4"–4" (DN10–DN100)

Wall Thickness: 0.6–2.0 mm

Applicable Standards: GB/T 19228.2-2011, CJ/T 152-2016, CJ/T 466-2014, EN, DIN, and ASME

Available Materials:

• 0Cr18Ni9, SS304, S30408, SUS304, and 1.4301

• 0Cr17Ni12Mo2, SS316, and SUS316

• SS304L, S30403, and 1.4306

• SS316L, S31603, and 1.4404

Sealing-Ring Materials: CIIR, EPDM, PTFE, and NBR

Connection Type: S-Type Press Connection

Nominal Pressure: PN16

Hydrostatic Test Pressure: 2.5 MPa

Airtightness Test Pressure: 1.05 MPa

Gasket Temperature Range: -20°C to +110°C, depending on the selected material and medium

Manufacturing Process: Mechanically formed from stainless steel pipes

Surface Treatment: Vibration Polishing, Magnetic Polishing, or Pickling

Product Marking: LOGO + OD + Wall Thickness + Material. Customized markings are available.

Packaging: Plastic Bags, Export Cartons, and Wooden Cases

Certificates: GB/T 19001-2016, ISO 9001:2015, CE documentation for applicable products, and Sanitary License

Brand: LIANHE

HS Code: 7307230000

Place of Origin: Wenzhou, Zhejiang, China

Applications

Suitable for compatible drinking water, cold and hot water, wastewater, industrial water, oil, and gas systems.

Typical applications include water supply, heating, air conditioning, industrial piping, commercial buildings, residential buildings, ships, hospitals, and hotels.

Product Advantages

1. Connects two pipes of the same diameter

2. Fast, flame-free installation

3. Good corrosion resistance

4. Low flow resistance

5. Reliable sealing when correctly installed

6. Good vibration resistance

7. Reduced installation time and labor costs

8. Multiple materials and sealing rings available

Installation

1. Cut the pipe squarely and remove internal and external burrs.

2. Clean the pipe ends and fitting sockets.

3. Check that the sealing rings are correctly positioned.

4. Mark the required insertion depth.

5. Insert both pipes fully into the coupling.

6. Use a press tool and jaw compatible with the specified S-type profile.

7. Inspect both joints and perform the required pressure or leakage test.

Quality Control

Standard inspection includes raw-material verification, wall-thickness measurement, socket inspection, surface inspection, hydraulic and airtightness testing, product marking, and packaging inspection.

Available documents include EN 10204 3.1 Material Test Certificates, raw-material certificates, dimensional reports, hydraulic test reports, and third-party inspection reports. Radiographic testing reports may be supplied when applicable.

Commercial Terms

MOQ: Normally 5–10 pieces, depending on size and stock availability.

Free Samples: Available for selected standard products; express charges are normally paid by the recipient.

Quotation Time: Normally within three working hours.

Delivery Time: Approximately 3–7 days for regular products and approximately 25 days for new production.

Payment Terms: 30% T/T deposit and 70% balance before delivery.

Shipping Terms: EXW, FOB, CFR, CIF, DDP, and DDU.

Warranty: One year against confirmed manufacturing defects.

Manufacturer: LIANHE
Place of Origin: Wenzhou, Zhejiang, China
