Stainless Steel Flange Ball Valve

Stainless Steel Flange Ball Valve provides manual quarter-turn on/off control through bolted flange connections. Confirm the flange standard, nominal size, pressure class, facing, bore, material grade and service conditions so both mating ends are compatible. Final specifications are subject to the approved drawing and quotation.

    Stainless Steel Flanged Ball Valve

    Product Description

    The LIANHE Stainless Steel Flanged Ball Valve provides manual on/off flow control in compatible water, oil, gas, and industrial piping systems.

    Its full-bore design helps reduce flow restriction, while the investment-cast stainless steel body provides corrosion resistance and mechanical strength.

    Technical Specifications

    Size Range: 1/4"–4" (DN8–DN100), Full Bore

    Connection Type: Flanged Connection

    Applicable Flange Standards: ASME/ANSI B16.5, JIS B 2220, EN 1092-1, BS 4504, GB/T 9119, HG/T 20592, and GOST 12821

    Working Pressure: Up to 1,000 PSI for compatible W.O.G. applications, subject to valve size, flange rating, material, and temperature

    Manufacturing Process: Investment-Cast Body with Precision CNC Machining

    Operation: Manual Lever Handle; Locking Handle Available

    Stem: Blowout-Resistant Design with Adjustable Packing

    Seat and Seal Material: PTFE

    Temperature Range: -60° to 450°; temperature unit and PTFE compatibility must be confirmed

    Leakage Test: Air tested under water at 100 PSI

    Available Body Materials:

    • SS304, CF8, SUS304, and 1.4308

    • SS316, CF8M, SUS316, and 1.4408

    • SS304L

    • SS316L

    Handle and Nut Materials: SS201, SS304, or SS316 according to customer requirements

    Brand: LIANHE

    HS Code: 8481804090

    Certificates: GB/T 19001-2016, ISO 9001:2015, and CE documentation for applicable products

    Place of Origin: Wenzhou, Zhejiang, China

    Product Advantages

    1. Full-bore flow passage

    2. Flanged pipeline connection

    3. Manual quarter-turn operation

    4. Blowout-resistant stem

    5. Adjustable stem packing

    6. Good corrosion resistance

    7. Locking handle option

    8. Multiple flange standards and materials available

    The flange standard, pressure rating, facing, bolt pattern, gasket, temperature, and medium compatibility must be confirmed before ordering.

    Quality and Inspection

    Available documents include:

    • EN 10204 3.1 Material Test Certificate

    • Raw-Material Inspection Certificate

    • Hydraulic Test Report

    • Air Leakage Test Report

    • Flange and Dimensional Inspection Report

    • Radiographic Testing Report, when applicable

    • Third-Party Inspection Report

    Quality-control personnel inspect raw materials, casting, machining, assembly, sealing performance, flange dimensions, markings, and packaging before shipment.

    Commercial Terms

    OEM: Available according to customer drawings and specifications.

    Payment Terms: 30% deposit with the balance paid before delivery. T/T, Western Union, PayPal, and other agreed methods are available.

    Shipping Terms: EXW Wenzhou, FOB Ningbo or Shanghai, CFR, CIF, DDP, and DDU.

    Transportation: Land, sea, air, or international express.

    Manufacturer: LIANHE
    Place of Origin: Wenzhou, Zhejiang, China
