Stainless Steel Sanitary Clamp Butterfly Valve
  • Stainless Steel Sanitary Clamp Butterfly ValveStainless Steel Sanitary Clamp Butterfly Valve
  • Stainless Steel Sanitary Clamp Butterfly ValveStainless Steel Sanitary Clamp Butterfly Valve
  • Stainless Steel Sanitary Clamp Butterfly ValveStainless Steel Sanitary Clamp Butterfly Valve

Stainless Steel Sanitary Clamp Butterfly Valve

Stainless Steel Sanitary Clamp Butterfly Valve provides quarter-turn flow control in a compatible hygienic line. Confirm the clamp connection dimensions, stainless steel grade, seat material, handle or actuator arrangement and operating conditions against the approved drawing and quotation.


    Product Introduction

    The LIANHE Stainless Steel Sanitary Clamp Butterfly Valve is a premium-grade flow control solution designed for quick installation, easy maintenance, and superior hygiene, making it ideal for use in the food, beverage, dairy, pharmaceutical, and biotechnology industries.

    Engineered and polished to Ra≤0.8μm, the internal surface minimizes product adhesion and bacterial growth, ensuring consistent hygiene and product safety.



    Stainless Steel Sanitary Clamp Butterfly Valve Product Specifications

    Size: 1/2”~6" (DN15~DN150);



    Standard: 3A SMS IDF DIN;



    Material: SS304 S30408,SS316 S31603,SS304L S30403,SS316L S31603;

    Sealing Material: VMQ,EPDM,FPM(Adopt import sealing materials,with all the seal material the FDA117.2600);



    Body Type: Weld-Weld,Male-Male Thread,Clamp-Clamp,Weld-Male Thread, Weld-Clamp, Male Thread-Liner,Male Thread-Flange,Three-Piece,Flange-Flange;



    Butterfly valve handle type: Lever Handle, Duck bill stainless steel handle,Duck bill plastic handle;



    Driving mode: Manual, Electric, Pneumatic;



    Pressure of Work: 0~10Bar; Control air Pressure: 5~8Bar;



    Working Temperature: VMQ:-50~+180℃ EPDM:-20~+135℃ FPM: -30~+230℃

    Sterilization Temperature: 150℃ (MAX 20min)



    Surface Treatment: Inside: Ra≥0.4-0.8um,Outside:Ra≥0.8~1.6um



    Mark: Logo-SIZE-Material-Standard;



    Processing technology: Forging, Machining;



    Packing: Bubble wrap or Plastic package-Cartons-Wrapped in woven bags-Wooden Case;



    Certificates: GB/T19001-2016,ISO9001:2015,CE;



    Factory Inspection Report and Certificates:

    EN 10204/3.1B-MTC;

    Raw material inspection certificate;

    100% Radiography Test Report;

    Hydraulic seal test report;

    Third Party Inspection Report, etc;



    Brand: LIANHE;



    HS Code: 7307290000



    Payment Term: 30%TT Advance Payment+70%TT Payment Before Delivery;( Note: Specific can be discussed.)



    Available via T/T, Western Union, Paypal Etc. Payment for goods;



    Place of Origin: Wenzhou,China



    Typical Applications

    • Food & beverage processing (dairy, breweries, soft drinks)

    • Pharmaceutical & biotech production

    • Clean-in-place / Sterile liquid handling systems

    • Cosmetic & personal care manufacturing

    • Cleanroom and sterile piping networks

    • Bioprocessing, fermentation, and cell culture systems



    Key Features

    • Hygienic Design: Built with sanitary-grade stainless steel (SS304, SS316, SS304L, SS316L) and a smooth internal finish to minimize contamination risk and ensure easy cleaning.

    • Quick Installation: The clamp connection design enables fast, tool-free assembly and disassembly—ideal for frequent maintenance or cleaning-in-place (CIP) systems.

    • Durable Construction: Manufactured through precision forging and machining to provide excellent corrosion resistance and long service life under demanding process conditions.

    • FDA-Compliant Seals: Equipped with VMQ, EPDM, or FPM sealing materials that meet FDA 177.2600 standards, offering compatibility with food, beverage, and pharmaceutical applications.

    • Versatile Operation Modes: Available in manual, electric, or pneumatic actuation to meet diverse system requirements.

    • Flexible Body Configurations: Offered in clamp-clamp, weld-clamp, threaded-clamp, three-piece, and other body types for integration with various sanitary piping systems.
