Lightweight Stainless Steel 2-Piece Thread Ball Valve for Commercial Use
Stainless Steel 2-Piece Thread Ball Valve provides manual quarter-turn on/off control for a compatible line. Confirm the female thread form and size, valve bore, material grade and operating conditions before ordering. Final specifications are subject to the approved drawing and quotation.
The Lightweight Stainless Steel 2-Piece Thread Ball Valve is a compact, easy-to-install solution for on/off flow control in low-to-medium pressure systems. Constructed from 304 stainless steel, this valve features NPT threads (ANSI B1.20.1) and a lightweight design, making it ideal for commercial plumbing, HVAC, and light industrial applications where space and weight are critical.
Features
Compact & Lightweight Design:
30% lighter than equivalent cast iron valves (e.g., 0.5kg for 1" size), reducing strain on overhead pipelines and portable equipment.
Two-piece body with union connection for easy maintenance, allowing stem and seat replacement without disconnecting the pipeline.
Reliable Sealing Performance:
PTFE seat provides bubble-tight shutoff (API 598) up to 100 PSI, with a polished ball (Ra ≤0.8μm) ensuring low operating torque (≤8 N·m for 1" valves).
Blowout-proof stem design and anti-static spring (dissipates static charge in gas applications) enhance safety compliance.
Threaded Connection Advantages:
NPT male/female threads for quick assembly/disassembly, compatible with steel, copper, and PEX pipes, eliminating the need for welding or press tools.
Thread sealant not required for water applications; optional PTFE tape recommended for gas systems to enhance leak resistance.
Operational Flexibility:
Temperature range: -20°C to 180°C (PTFE seat), suitable for hot water, compressed air, and non-corrosive liquid lines.
Available in full-port (100% flow efficiency) and reduced-port (space-saving) options, with sizes ranging from 1/4" to 2" NPS.
Application
Perfect for commercial and light industrial settings:
Plumbing & Residential: Water supply lines, shutoff valves for sinks/faucets, and radiant floor heating systems, compliant with NSF/ANSI 61 for potable water.
HVAC Systems: Control valves for air conditioning condensate lines and small refrigerant pipes in rooftop units and data centers.
Food Service: Beverage dispensing systems and ice machine connections, with 304 stainless steel meeting FDA requirements for indirect food contact.
Laboratory Equipment: On/off control for non-corrosive reagent lines and vacuum systems, with reduced-port models suitable for low-flow applications.
FAQ
Q: Can this valve be used with steam?
A: Limited to 150°C (PTFE seat); for higher temperatures, choose a valve with an RPTFE seat (up to 260°C).
Q: What is the difference between full-port and reduced-port models?
A: Full-port valves have the same bore as the pipe (e.g., 1" bore for 1" valve), while reduced-port valves have a 20% smaller bore for compactness.
Q: How to lubricate the stem for smooth operation?
A: Apply a food-grade lubricant (e.g., silicone grease) to the stem packing every 6-12 months, depending on usage frequency.
Q: Is the valve suitable for buried installations?
A: Yes, but use a valve box for access and protect threads with anti-corrosion tape to prevent soil moisture damage.
